IR Patrol LE100C 640X480 Thermal Image Capture Monocular

$5,999.00
(No reviews yet) Write a Review

Out of stock

Shipping:
Free Shipping
SKU: IRMO-100C
UPC: 719307800731
Device Technology: Thermal Imaging
Sensor Resolution: 640x480
Optical Magnification: 1X
Sensor Pixel Size: 12 Micron
Sensor Frame Rate: 30hz
Objective Focal Length: 19mm
Objective F#: 1.1
Detection Range: 1350
Digital Magnification: 8X
The IR Patrol is packed full of features exclusive to the commercial thermal market including Quick Command Control, and a fully ruggedized thumb stick controller. The IR Patrol is also the most affordable 640 resolution thermal monocular ever to hit the commercial, LE, and military market. The IR Patrol combines the latest technology 12 micron BAE thermal core with miniaturized electronics to create a user friendly rugged waterproof package taking LE and night hunters to the next level of thermal imagery.

Thumb Stick Controller
The IR Patrol comes standard equipped with a multi-directional fully ruggedized, weather-proof thumb stock control. The thumb stick is large and easy to find in the dark and is much quicker and easier to use than conventional buttons found on nearly every other thermal system on the market.

QCM - Quick Command Mode
Quick Command Mode(QCM) is featured in all models of the IR Patrol. QCM is a an extremely advantageous tactical feature that is completely user configurable. QCM allows the user to configure 4 icons as seen below, each of which is controlled by the movement of the thumb stick controller in that direction. QCM allows you to configure each location to which ever icon you choose. If you want the same icon in all locations, you can do that. These icons are set by moving the thumb stick in the direction you wish to set while holding the thumb stuck in that direction, each button press will change the icon type. Once you have the icon you desire, release and you are done. The thumb stick featured on the IR Patrol is the easiest to use control system on the market, and with QCM the IR Patrol offers full customization.


Compatibility with Afocal Magnifiers/Len Multipliers
The 2X and 3X afocal magnifying lenses compatible with the IR Patrol will double or triple your lens magnification and detection range. This is the most cost effective way to increase you lens magnification and usable range while still retaining the ability to quickly remove the magnifier and use a wide angle 1X field of view.


The IR Patrol meets the need to see in the dark for military, first responders, and sportsmen alike. With limited budgets, quality thermal products are typically out of reach and that's where the IR Patrol comes in. The new IR Patrol thermal monocular solves this problem, as IR Defense has developed one of the most affordable, high resolution, thermal night vision devices on the market.

Performance, Durability and Affordability
Whether you are protecting our borders, searching for a lost child, or eradicating groups of feral hogs, operators need high resolution thermal images in a small robust device. The IR Patrol thermal monocular is a game changer for the night vision industry. For the first time ever, night vision users can enjoy thermal high definition imagery for under five thousand dollars ($5,000.00 USD).

The IR Patrol features an advanced user interface with a military grade thumb stick that is the perfect size - no more searching for buttons in the dark. With the monocular's ergonomic design, users can take advantage of all the functionality, including the menu system that is engineered to be intuitive and efficient to operate.

Quality, Quality and Quality
The IR Patrol was designed for military applications at a consumer affordable price point. All the components inside the IR Patrol are the highest quality. The BAE Systems long wave infrared (LWIR) uncooled, 30Hz thermal core, combined with Emagin's OLED, 10,000:1 contrast VGA display and our 6061 aircraft aluminum housings, are the highest quality system components available. All made in the USA.

The IR Patrol LE100C Thermal Monocular features a 640x480 thermal image at 30Hz frame rate. Polarity Digital E-Zoom, brightness, and DFC Digital focus give operational control of the system. The LE100C also includes image capture, allowing the user to save pictures in the system and download them later with the included download cable.


Includes:
  • IR PATROL Sight
  • Eyecup
  • Tactical Soft Case
  • Lanyard
  • Lens Cap
  • Operator's Manual
  • QRG Guide and Batteries
  • Download Cable
  • Download PC Software (USB Stick)
  • Download Instructions






  • 640x480 EMAGIN OLED Display
  • BAE MicroIR 640x480 12um Sensor
  • 30Hz Frame Rate
  • 19mm Objective Lens
  • MaxPol - multi-polarity technology provides three modes of white and black-hot allowing the user to better bring out the target or the background, depending on conditions
  • E-Zoom - digital zoom function enabling digital magnification of 2x, 4x, and 8x
  • DFC Digital Focus - finer detail, more contrast, and greater depth are simply achieved with a toggle and press of the joystick while viewing images through the IR Patrol
  • Image Capture Feature
  • Download Cable Included
  • PC Software Included

SENSOR SPECIFICATIONS

Sensor Type BAE MicroIR VOx Uncooled Microbolometer
Sensor Resolution 640x480 (actual 640x480) 307,200 pixels
SpectralL Band 8 - 12 μm
Pixel Pitch 12 μm
Sensitivity <50 mK
Frame Rate 30Hz
Calibration NUC (Non Uniformity Correction)

OPTICAL SPECIFICATIONS
Lens Type Germanium
IR Window Germanium with Protective DLC Coating
Focal Length 19mm
F/# f/1.1
Transmission 0.88
Eye Relief 27mm
Diopter -1.5

DISPLAY SPECIFICATIONS
Type Emagin OLED Monochrome Display
Resolution VGA 640x480
Output 10 bit Digital Monochrome
Contrast >10,000:1
Frame Rate 30Hz

SYSTEM SPECIFICATIONS
Magnification 640x480 19mm - 1.x optical 8x digital
Field of View 640x480 19mm - 22° optical 3° digital
Dimensions 5.95" L x 2.0" H x 2.95" W
Weight >454 grams
Start Up Time >4 Seconds

FEATURES SPECIFICATIONS
User Interface Thumb Stick Controller
Polarity MaxPOL White Hot / Black Hot
Electronic Zoom Up to 8X Zoom
Laser Rail Built in Laser Interface Picatinny Rail
DFC - Digital Focus Enhances and Sharpens Imagery
Image Capture Image Capture
Video Output RS-170 NTSC Analog Video Special Cable required
Contrast User Adjustable Contrast
Reticle System None

  • Display

    Warranty

    3-Years

    Display Type

    eMagin OLED

    Video Output

    Analog RS-170/NTSC via

    Image Capture

    100 640x480 JPEG/BMP

    Onboard Recording

    No

    Bluetooth

    No

    Wifi

    No

    Recoil Rating

    None

    Country of Manufacture

    USA

  • Environmental Specifications

    Operating Temperature Range

    -40C/-40F to +55C/131F

    Storage Temperature Range

    -45C/-49F to +75C/167F

    Power Source

    1X or 2X CR123A Lithium

    Run Time

    2 - @ 30HZ 5 hrs;1 - @ 60hz 1.5 hrs; UNV Adapter @ 60hz 18 hrs+

  • Lens Specifications

    Optical Magnification

    1X

    Objective Lens Material

    Umicore GASIR

    Housing Material

    7000 series Aluminum/ABS

    Materials

    Aluminum/ABS/Steel/Copper/Glass/Germanium

    Objective Focal Length

    19mm

    Objective F#

    1.1

    Focusing Mechanism

    Manual

    Horizontal Angular Field of View

    40

    Vertical Angular Field of View

    40

    Detection Range

    1350

    Eyepiece Focal Length

    27mm

    Eye Relief

    27mm

    Exit Pupil

    14mm

    Diopter Range

    -6 to +2

    Connector Type

    9 Pin Fischer

    Connector Output

    Video/USB

    Reticle

    None

    Startup Time

    Under 5 Seconds

    Digital Magnification

    8X

  • Physical

    Length in/mm

    5.95 / 151

    Width in/mm

    2.95 /75

    Height in/mm

    2.0 /51

    Weight lb/gr

    1.0 lb / 16.0 oz / 454 gm

  • Sensor Specifications

    Device Technology

    Thermal Imaging

    Sensor Resolution

    640x480

    Sensor Pixel Size

    12 Micron

    Sensor Frame Rate

    30hz

    Thermal Sensitivity

    <50mk

    Spectral Response

    8-12 Microns

    Sensor Type

    BAE MicroIR Core
