IR Patrol M250-K Helmet Mounted Thermal Monocular Kit
- Shipping:
- Free Shipping
SKU: | IRMO-250K |
UPC: | |
Device Technology: | Thermal Imaging |
Sensor Resolution: | 640x480 |
Optical Magnification: | 1X |
Sensor Pixel Size: | 12 Micron |
Sensor Frame Rate: | 60hz |
Objective Focal Length: | 19mm |
Objective F#: | 1.1 |
Digital Magnification: | 8X |
Detection Range: | 1350 |
Military, First Responders, and Sportsmen all have a need to see in the dark, but with limited budgets, quality products are typically out of reach. The new IR Patrol thermal monocular solves this problem, as IR Defense has developed one of the most affordable, high resolution, thermal night vision devices on the market.
Performance, Durability and Affordability
Whether you are protecting our borders, searching for a lost child, or eradicating groups of feral hogs, operators need high resolution thermal images in a small robust device. The IR Patrol thermal monocular is a game changer for the night vision industry. For the first time ever, night vision users can enjoy thermal high definition imagery for under five thousand dollars ($5,000.00 USD).
The IR Patrol features an advanced user interface with a military grade thumb stick that is the perfect size - no more searching for buttons in the dark. With the monocular's ergonomic design, users can take advantage of all the functionality, including the menu system that is engineered to be intuitive and efficient to operate.
Quality, Quality and Quality
The IR Patrol was designed for military applications at a consumer affordable price point. All the components inside the IR Patrol are the highest quality. The BAE Systems long wave infrared (LWIR) uncooled, 60Hz thermal core, combined with Emagin's OLED, 10,000:1 contrast VGA display and our 6061 aircraft aluminum housings, are the highest quality system components available. All made in the USA.
The IR Patrol M250-K Helmet Mounted Kit steps up the performance to 60Hz fast frame rate delivering sharp, detailed imagery. The system features the Wilcox Shoe Interface to allow helmet mounting for hands-free use. Even more, the M250 includes edge detection mode for tactical use.
Includes:
- IR PATROL Sight
- Eyecup
- Tactical Soft Case
- Lanyard
- Lens Cap
- Operator's Manual
- QRG Guide and Batteries
- Wilcox Shoe Interface
- Wilcox Helmet Interface Kit
- Download Cable

- 640x480 EMAGIN OLED Display
- BAE MicroIR 640x480 12um Sensor
- 60Hz Frame Rate
- Edge Detect mode - allows the user to better identify targets at a distance, and provides additional perspective by its unique trace-outline image
- 19mm Objective Lens
- Wilcox Shoe Interface Adapter - allows for helmet mounting
- MaxPol - multi-polarity technology provides three modes of white and black-hot allowing the user to better bring out the target or the background, depending on conditions
- E-Zoom - digital zoom function enabling digital magnification of 2x, 4x, and 8x
- DFC Digital Focus - finer detail, more contrast, and greater depth are simply achieved with a toggle and press of the joystick while viewing images through the IR Patrol
- Configuration Level
- Image Capture Feature
SENSOR SPECIFICATIONS
Sensor Type | BAE MicroIR VOx Uncooled Microbolometer |
Sensor Resolution | 640x480 (actual 640x480) 307,200 pixels |
SpectralL Band | 8 - 12 μm |
Pixel Pitch | 12 μm |
Sensitivity | <50 mK |
Frame Rate | 60Hz |
Calibration | NUC (Non Uniformity Correction) |
OPTICAL SPECIFICATIONS
Lens Type | Germanium |
IR Window | Germanium with Protective DLC Coating |
Focal Length | 19mm |
F/# | f/1.1 |
Transmission | 0.88 |
Eye Relief | 27mm |
Diopter | -1.5 |
DISPLAY SPECIFICATIONS
Type | Emagin OLED Monochrome Display |
Resolution | VGA 640x480 |
Output | 10 bit Digital Monochrome |
Contrast | >10,000:1 |
Frame Rate | 60Hz |
SYSTEM SPECIFICATIONS
Magnification | 640x480 19mm - 1.x optical 8x digital |
Field of View | 640x480 19mm - 22° optical 3° digital |
Dimensions | 5.95" L x 2.2" H x 2.95" W |
Weight | >454 grams |
Start Up Time | >4 Seconds |
FEATURES SPECIFICATIONS
User Interface | Thumb Stick Controller |
Polarity | MaxPOL White Hot / Black Hot |
Edge Detect | Edge Detection Mode |
Electronic Zoom | Up to 8X Zoom |
Laser Rail | Built in Laser Interface Picatinny Rail |
DFC - Digital Focus | Enhances and Sharpens Imagery |
Image Capture | Image Capture |
Video Output | RS-170 NTSC Analog Video Special Cable required |
Contrast | User Adjustable Contrast |
ETR - Enhanced Target Recognition | Target Enhancement Software |
Head Mountable | M250 / M300W Only |
Reticle System | None |
-
Display
- Warranty
-
3-Years
- Display Type
-
eMagin OLED
- Video Output
-
Analog RS-170/NTSC via
- Image Capture
-
100 640x480 JPEG/BMP
- Onboard Recording
-
No
- Bluetooth
-
No
- Wifi
-
No
- Recoil Rating
-
None
- Country of Manufacture
-
USA
-
Environmental Specifications
- Operating Temperature Range
-
-40C/-40F to +55C/131F
- Storage Temperature Range
-
-45C/-49F to +75C/167F
- Power Source
-
1X or 2X CR123A Lithium
- Run Time
-
2 - @ 30HZ 5 hrs;1 - @ 60hz 1.5 hrs; UNV Adapter @ 60hz 18 hrs+
-
Lens Specifications
- Optical Magnification
-
1X
- Objective Lens Material
-
Umicore GASIR
- Housing Material
-
7000 series Aluminum/ABS
- Materials
-
Aluminum/ABS/Steel/Copper/Glass/Germanium
- Objective Focal Length
-
19mm
- Objective F#
-
1.1
- Focusing Mechanism
-
Manual
- Horizontal Angular Field of View
-
30 yds at 100 yrds
- Eyepiece Focal Length
-
27mm
- Eye Relief
-
27mm
- Exit Pupil
-
14mm
- Diopter Range
-
-6 to +2
- Connector Type
-
9 Pin Fischer
- Connector Output
-
Video/USB
- Reticle
-
None
- Startup Time
-
Under 5 Seconds
- Digital Magnification
-
8X
- Detection Range
-
1350
-
Physical
- Length in/mm
-
5.95 / 151
- Width in/mm
-
2.95 /75
- Height in/mm
-
2.0 /51
- Weight lb/gr
-
1.0 lb / 16.0 oz / 454 gm
-
Sensor Specifications
- Device Technology
-
Thermal Imaging
- Sensor Resolution
-
640x480
- Sensor Pixel Size
-
12 Micron
- Sensor Frame Rate
-
60hz
- Thermal Sensitivity
-
<50mk
- Spectral Response
-
8-12 Microns
- Sensor Type
-
BAE MicroIR Core
- Warranty
- 3-Years
- Thermal Sensitivity
- <50mk
- Spectral Response
- 8-12 Microns
- Objective Lens Material
- Umicore GASIR
- Housing Material
- 7000 series Aluminum/ABS
- Materials
- Aluminum/ABS/Steel/Copper/Glass/Germanium
- Focusing Mechanism
- Manual
- Horizontal Angular Field of View
- 30 yds at 100 yrds
- Eyepiece Focal Length
- 27mm
- Eye Relief
- 27mm
- Exit Pupil
- 14mm
- Diopter Range
- -6 to +2
- Operating Temperature Range
- -40C/-40F to +55C/131F
- Storage Temperature Range
- -45C/-49F to +75C/167F
- Power Source
- 1X or 2X CR123A Lithium
- Run Time
- 2 - @ 30HZ 5 hrs;1 - @ 60hz 1.5 hrs; UNV Adapter @ 60hz 18 hrs+
- Length in/mm
- 5.95 / 151
- Width in/mm
- 2.95 /75
- Height in/mm
- 2.0 /51
- Weight lb/gr
- 1.0 lb / 16.0 oz / 454 gm
- Display Type
- eMagin OLED
- Display Resolution
- 640x480
- Video Output
- Analog RS-170/NTSC via
- Image Capture
- 100 640x480 JPEG/BMP
- Onboard Recording
- No
- Bluetooth
- No
- Wifi
- No
- Recoil Rating
- None
- Country of Manufacture
- USA
- Connector Type
- 9 Pin Fischer
- Connector Output
- Video/USB
- Reticle
- None
- Startup Time
- Under 5 Seconds
- User Interface
- Thumbstick
- Mounting Interface
- Picatinny / Dovetail
- Product Name
- IR Patrol M250-K Helmet Mounted Thermal Monocular Kit
- Length
- 5.95 / 151
- Operating Storage Temperature Range
- -40C/-40F to +55C/131F
- Weight
- 1.0 lb / 16.0 oz / 454 gm
- Height
- 2.0 /51
- Width
- 2.95 /75
- Sensor Type
- BAE MicroIR Core
